• Country
• Sweden

• Manufacturer / Brand
• Centrum-Radio, Gylling & Co.; Stockholm

• Year
• 1953 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 149686

• • Brand: Gylling

• Number of Tubes
• 3

• Valves / Tubes
• UCH81 UBF80 UCL81

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 120-220 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known. / Ø 13.5 cm = 5.3 inch

• Power out
• 2 W (unknown quality)

• from Radiomuseum.org
• Model: Junior 198 - Centrum-Radio, Gylling & Co.;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 300 x 221 x 158 mm / 11.8 x 8.7 x 6.2 inch

• Notes
• + rectifier 12-17. Frequency bands: LW: 690-2000m, BC: 187-577m, SW:16,7-51m Price is from August 1953.

• Price in first year of sale
• 195.00 SEK

• Author
• Model page created by Jörgen Svensson. See "Data change" for further contributors.
