CR647VT
Cibot Radio; Paris
- Country
- France
- Manufacturer / Brand
- Cibot Radio; Paris
- Year
- 1966
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 217189
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 480 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Dry Batteries / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: CR647VT - Cibot Radio; Paris
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 265 x 150 x 80 mm / 10.4 x 5.9 x 3.1 inch
- Literature/Schematics (1)
- - - Manufacturers Literature (Cibot Radio Catalogue No. 104/4 Novembre 1966)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
