• Country
• France

• Manufacturer / Brand
• Claronde; Paris

• Year
• 1949 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 119391

• Number of Tubes
• 6

• Valves / Tubes
• ECH42 EAF42 EAF42 EL41 EM34 GZ41

• Conflicting model year with tube data.
• The model date contradicts tube dates. [ GZ41 (1951)]

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 202 Luxe - Claronde; Paris

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 527 x 303 x 227 mm / 20.7 x 11.9 x 8.9 inch

• Notes
• Das Gerät hat eine deutsche Skala und könnte für den saarländischen Markt bestimmt gewesen sein.

• Net weight (2.2 lb = 1 kg)
• 7.9 kg / 17 lb 6.4 oz (17.401 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.

• Other Models

• Here you find 1 models, 1 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Claronde; Paris
