Conserton MD2508U /19

Stern & Stern (Concerton / Conserton), S&S; Stockholm

Data
Forum
Pictures
Collections

  • Year
  • 1958 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 193569

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 452/10700 kHz
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • AC/DC-set / 127; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Bakelite or Plastics (type unknown)
  • from Radiomuseum.org
  • Model: Conserton MD2508U /19 - Stern & Stern Concerton /
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 280 x 195 x 160 mm / 11 x 7.7 x 6.3 inch
  • Notes

  • See also the similar model Philips BD283U.

    Made in Belgium by Philips Leuven for Stern & Stern, Stockholm.

  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
