- Country
- France
- Manufacturer / Brand
- Continental Edison, Compagnie Continentale Édison; Paris
- Year
- 1957/1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 191302
Catalogue 1958
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 117; 125; 145; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 4.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: AR611 - Continental Edison, Compagnie
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 520 x 360 x 350 mm / 20.5 x 14.2 x 13.8 inch
- Notes
-
4 gammes d'ondes dont une bande etalée. HP elliptique. Grand cadre à air blindé rotatif. Antenne OC et BE incorporée.
Platine tourne-disque 4 vitesses: 16, 33, 45, 78 tours. Arrêt automatique. Tête de 2 saphirs reversibles 78 tours et microsillon.
Coffret noyer verni.
- Source of data
- -- Original-techn. papers.
- Mentioned in
- -- Original prospect or advert (Catalogue 1958)
- Literature/Schematics (1)
- Le grand livre de la TSF (Doctsf Ref 401)
- Author
- Model page created by Getulio Jimenez-Gomez. See "Data change" for further contributors.
