• Country
• Germany

• Manufacturer / Brand
• Continental-Rundfunk GmbH (Stassfurter Imperial); Osterode/Harz

• Year
• 1955/1956

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 20088

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• PCC84 PCC85 EF80 EF80 EF80 EF80 PCL81 PCC85 ECL80 PL36 PY81 EY86 EF80 PABC80 PL82 MW53-80

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Imperial FES521 - Continental-Rundfunk GmbH

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 675 x 920 x 570 mm / 26.6 x 36.2 x 22.4 inch

• Notes
• 12 Kanäle im VHF-Bereich.

• Net weight (2.2 lb = 1 kg)
• 58 kg / 127 lb 12.1 oz (127.753 lb)

• Price in first year of sale
• 1,298.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1955/56 / Radiokatalog Band 2, Ernst Erb

• Other Models

• Here you find 143 models, 127 with images and 88 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Continental-Rundfunk GmbH (Stassfurter Imperial); Osterode/Harz
