• Country
• France

• Manufacturer / Brand
• Grandin, Cristal-Grandin (SFRT); Paris, Montreuil

• Year
• 1959 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 205427

• Number of Tubes
• 6

• Valves / Tubes
• ECH81 EF93 6AB6 EL84 EM85 EZ80

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 173 - Grandin, Cristal-Grandin SFRT;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 520 x 320 x 210 mm / 20.5 x 12.6 x 8.3 inch

• Notes
• Aussi une gamme BE = Bande ecartée (OC).

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Author
• Model page created by João Luis Mendes Colaço. See "Data change" for further contributors.

• Other Models

• Here you find 281 models, 207 with images and 81 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
