• Country
• France

• Manufacturer / Brand
• Grandin, Cristal-Grandin (SFRT); Paris, Montreuil

• Year
• 1950/1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 68449

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6BE6 6BA6 6AV6 or 6AT6 6AQ5 6AF7 6X4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110 - 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Cristal-Grandin Charmeur 612 [alternatif] - Grandin, Cristal-Grandin SFRT;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 635 x 335 x 235 mm / 25 x 13.2 x 9.3 inch

• Notes

• 5 gammes d'ondes PO, GO, et 3 bandes OC étalées. Cadran miroir, conforme au plan de Copenhague.

  Existe aussi en version pour 25 périodes et en tous courants.

• Net weight (2.2 lb = 1 kg)
• 9.5 kg / 20 lb 14.8 oz (20.925 lb)

• Price in first year of sale
• 23,600.00 FRF

• Source of data
• -- Schematic

• Mentioned in
• Serge Laffont/Martin Renoth

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur 1951

• Literature/Schematics (2)
• -- Original prospect or advert (1951)
