- Country
- France
- Manufacturer / Brand
- Grandin, Cristal-Grandin (SFRT); Paris, Montreuil
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 199388
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Cristalette - Grandin, Cristal-Grandin SFRT;
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 150 x 172 x 155 mm / 5.9 x 6.8 x 6.1 inch
- Notes
-
Modèle identique au O.R.A. Menuet. Fonctionnant à 220-240 V en ajoutant un abaisseur de tension.
Voir aussi le modèle Cristalette 154U en courant alternatif.
Attention: danger de mort, appareil tous courant, châssis branché sur l’alimentation, il n’y a pas de fusible!
- Net weight (2.2 lb = 1 kg)
- 3.4 kg / 7 lb 7.8 oz (7.489 lb)
- Author
- Model page created by Bekir Yurdakul. See "Data change" for further contributors.
