Super-Secteur
Croizet, A.; Marseille
- Country
- France
- Manufacturer / Brand
- Croizet, A.; Marseille
- Year
- 1935 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 321070
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 180; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Super-Secteur - Croizet, A.; Marseille
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 460 x 455 x 265 mm / 18.1 x 17.9 x 10.4 inch
- Notes
-
Circuit présélecteur. Réglage de tonalité.
- Author
- Model page created by Francisco Perez Hurtado. See "Data change" for further contributors.
- Other Models
-
Here you find 3 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
