• Country
• France

• Manufacturer / Brand
• Depaèpe; Paris, Bois-Colombes

• Year
• 1938–1940 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 356317

• Number of Tubes
• 5

• Valves / Tubes
• 6E8MG 6K7G 6Q7G 25L6G 25Z6G

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12.5 cm = 4.9 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Inconnu - unknown 3 - Depaèpe; Paris, Bois-Colombes

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 240 x 180 x 140 mm / 9.4 x 7.1 x 5.5 inch

• Net weight (2.2 lb = 1 kg)
• 3.1 kg / 6 lb 13.3 oz (6.828 lb)

• Author
• Model page created by Bekir Yurdakul. See "Data change" for further contributors.

• Other Models

• Here you find 10 models, 9 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
