Boîte de résistances - Pont de mesure
Digeon et Cie, Louis, Mambret et Cie - voir aussi Branville; Paris
- Country
- France
- Manufacturer / Brand
- Digeon et Cie, Louis, Mambret et Cie - voir aussi Branville; Paris
- Year
- 1920 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 344908
Schematic processed by Gidi Verheijen.
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Dry Batteries
- Loudspeaker
- - - No sound reproduction output.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Boîte de résistances - Pont de mesure - Digeon et Cie, Louis, Mambret
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 360 x 280 x 210 mm / 14.2 x 11 x 8.3 inch
- Author
- Model page created by Philippe Viard. See "Data change" for further contributors.
- Other Models
-
Here you find 2 models, 1 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Digeon et Cie, Louis, Mambret et Cie - voir aussi Branville; Paris
Collections
The model Boîte de résistances - Pont de mesure is part of the collections of the following members.
