- Country
- France
- Manufacturer / Brand
- Ducastel Frères (DAHG); Clichy, Paris
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 70923
-
- Brand: DAHG
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Ø 16 cm = 6.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Minerve - Ducastel Frères DAHG; Clichy,
- Dimensions (WHD)
- 530 x 330 x 210 mm / 20.9 x 13 x 8.3 inch
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- External source of data
- Serge Laffont/Martin Renoth
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
