- Country
- France
- Manufacturer / Brand
- Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
- Year
- 1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 70943
-
- alternative name: SED
Face avant partie haute
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 115, 127, 150, 220, 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 3.8 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: L436 - Ducretet -Thomson; avant:
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 514 x 365 x 243 mm / 20.2 x 14.4 x 9.6 inch
- Notes
-
Il existe aussi un modèle pour secteurs de 25 Hz.
L'impédance de la bobine mobile du HP est de 2,5 ohms, ses dimensions sont 16 x 24 cm.
- Net weight (2.2 lb = 1 kg)
- 9.450 kg / 20 lb 13 oz (20.815 lb)
- External source of data
- Serge Laffont/Martin Renoth
- Source of data
- Le grand livre de la TSF
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
