• Country
• France

• Manufacturer / Brand
• Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris

• Year
• 1927–1929 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 105856

• • alternative name: SED

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• A441 A409 A409 A410 B403 B406

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Phonomodula PM6 - Ducretet -Thomson; avant:

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes
• Phonomodula PM6 avec changeur de fréquence par bigrille. Amplificatrice pour P.U.

• Mentioned in
• Le Guide du Collectionneur TSF Biraud/Foster, Vol. I (page 158)

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
