Autoport T52385
Dux Radio AB; Stockholm
- Country
- Sweden
- Manufacturer / Brand
- Dux Radio AB; Stockholm
- Year
- 1965
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 248335
Aus den Hersteller-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Semiconductors
- AF106 AF124 AF125 AF125 AF126 AF126 AC151 AC151 AC153 AC153 AA112 AA112 OA90 OA90 OA90 RD10E E15C5 BA102 SZL7
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Batteries / addl. power jack
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2 W (max.)
- Material
- Various materials
- from Radiomuseum.org
- Model: Autoport T52385 - Dux Radio AB; Stockholm
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
Für dieses Gerät gab es auch eine Autohalterung. Beim Einschub in die Halterung erfolgte die Spannungsversorgung über die Autobatterie. Außerdem konnte man das Radio mit einer Fahrzeug-Außenantenne betreiben.
Parallelgerät zu Loewe Opta Autoport TS 52 385.
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
