• Country
• Sweden

• Manufacturer / Brand
• Dux Radio AB; Stockholm

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 249140

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 inch = 17.8 cm

• Power out
• 2.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Dixie V422 - Dux Radio AB; Stockholm

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 535 x 190 x 180 mm / 21.1 x 7.5 x 7.1 inch

• Notes

• Speaker: Philips AD3700M (Z = 5 Ohm).

• Net weight (2.2 lb = 1 kg)
• 3.9 kg / 8 lb 9.4 oz (8.59 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
