• Country
• Sweden

• Manufacturer / Brand
• EIA Elektriska Industri AB; Stockholm

• Year
• 1955 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 206798

• • alternative name: Elektriska Industri AG

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 EF89 ECH81 EF89 EM80 EABC80 EL84

• Number of Transistors

• Semiconductors
• Tr.Gl.=Metal-rectif.

• Main principle
• Superhet with RF-stage

• Tuned circuits
• 6 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-125; 220-240 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Kongo V5688 Ch= Blaupunkt H2154-EIA - EIA Elektriska Industri AB;

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1020 x 800 x 401 mm / 40.2 x 31.5 x 15.8 inch

• Notes
• EIA Kongo V5688 is an import model, manufactured by Blaupunkt for the Swedish market.
  Lettering of the dial and back cover is in Swedish language.
  Similar German model is the Blaupunkt Kongo 3D where the corresponding chassis is Blaupunkt H2154.

• Net weight (2.2 lb = 1 kg)
• 33.5 kg / 73 lb 12.6 oz (73.789 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Frank Van de Ven. See "Data change" for further contributors.
