• Country
• Germany

• Manufacturer / Brand
• Emud, Ernst Mästling; Ulm

• Year
• 1957/1958

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 99538

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• AW43-80

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Condor 43T858 - Emud, Ernst Mästling; Ulm

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 560 x 500 x 450 mm / 22 x 19.7 x 17.7 inch

• Notes

• VHF-Band I und III

• Net weight (2.2 lb = 1 kg)
• 32 kg / 70 lb 7.8 oz (70.485 lb)

• Price in first year of sale
• 858.00 DM

• Source of data
• HdB d.Rdf-& Ferns-GrH 1957/58

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
