Radio Union 1 (RU 1 GW)

• Country
• Germany

• Manufacturer / Brand
• Emud, Ernst Mästling; Ulm

• Year
• 1936/1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 241084

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• CF7 CL4 AZ1

• Number of Transistors

• Semiconductors
• U1230/34

• Main principle
• TRF with regeneration

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Radio Union 1 - Emud, Ernst Mästling; Ulm

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 540 x 295 x 245 mm / 21.3 x 11.6 x 9.6 inch

• Notes

• Siehe auch Radio-Union Typ 1 RU1GW.

• Price in first year of sale
• 129.00 RM

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
