Astor 5

• Country
• France

• Manufacturer / Brand
• Astor (marque)

• Year
• 1934/1935 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216702

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 78 77 43 25Z5

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 110; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 cm = 4.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Astor 5 - Astor marque

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 250 x 200 x 130 mm / 9.8 x 7.9 x 5.1 inch

• Notes

• 2 gammes d'ondes de 200 à 2000 m. Contrôle de tonalité. Prise pick-up. Fonctionne sur antenne réduite (2 mètres).

  Mallette en cuir sur demande.

  Attention danger : châssis relié au secteur.

• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• Price in first year of sale
• 995.00 FRF

• Mentioned in
• -- Original prospect or advert (Catalogue Radio-Prim 1934/1935)

• Author
• Model page created by Bekir Yurdakul. See "Data change" for further contributors.
