• Country
• France

• Manufacturer / Brand
• Fedha, Combes-Gensac; Bordeaux

• Year
• 1931 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 246930

• Number of Tubes
• 5

• Valves / Tubes
• TM4 AS495 E415 F10 506

• Main principle
• Superheterodyne (common); ZF/IF 55 kHz; 1 AF stage(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 130; 220; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - Unknown 3 - Fedha, Combes-Gensac; Bordeaux

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 480 x 600 x 270 mm / 18.9 x 23.6 x 10.6 inch

• Net weight (2.2 lb = 1 kg)
• 14.6 kg / 32 lb 2.5 oz (32.159 lb)

• Author
• Model page created by Guy De Visch. See "Data change" for further contributors.

• Other Models

• Here you find 26 models, 24 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
