• Country
• France

• Manufacturer / Brand
• Ferisol; Paris

• Year
• 1968

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 202869

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ZA1004 ZA1004 CL703CL CL703CL

• Number of Transistors
• 19

• Semiconductors
• ASZ15 BDY11 2N1566 2N1309 2N2905 2N1308 2N3330 1N3190 1N714A 1N718A 1N983 OA90 OA47 T13G

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 120; 127; 220; 240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Special material, described in the notes.

• from Radiomuseum.org
• Model: Millivoltmètre UHF 5702 - Ferisol; Paris

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 230 x 260 x 296 mm / 9.1 x 10.2 x 11.7 inch

• Notes
• Semiconductors listed once per type.
  Millivoltmètre alternatif tropicalisé de 10kHz à 900 MHz.
  Le voltmètre 5702 est logé dans un coffret en alkyde métallisé intérieurement dont l'étanchéité sur panneau avant est assurée par un joint silastène.

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Claude Brunet. See "Data change" for further contributors.
