Air Chief R-1661 Ch= R-166

Firestone Tire & Rubber Co. (Air Chief & Roamer, Airchief); Akron (OH)

Données
Forum
Images
Collections

  • Année
  • 1937 ?
  • Catégorie
  • Radio - ou tuner d'après la guerre 1939-45
  • Radiomuseum.org ID
  • 40700

Cliquez sur la vignette du schéma pour le demander en tant que document gratuit.

 Spécifications techniques

  • No. de tubes
  • 7
  • Principe général
  • Super hétérodyne (en général); FI/IF 456 kHz; 2 Etage(s) BF
  • Circuits accordés
  • 6 Circuits MA (AM)
  • Gammes d'ondes
  • GO, OC et Police (Maritime)
  • Tension / type courant
  • Alimentation Courant Alternatif (CA) / Either transformer: 60 cycles, 115V or 25 - 133 cycles, 100-240 Volt
  • Haut-parleur
  • HP dynamique à électro-aimant (électrodynamique) / Ø 8 inch = 20.3 cm
  • Matière
  • Boitier en bois
  • De Radiomuseum.org
  • Modèle: Air Chief R-1661 Ch= R-166 - Firestone Tire & Rubber Co.
  • Forme
  • Modèle de table sans poussoirs, modèle cheminée
  • Remarques

  • The Firestone Air Chief R-1661 is an AC operated 7 tube BC, Police and SW band receiver. Has tuning eye tube.

    Note: There are a few minor production changes noted on the Riders schematic (Page 7-3) for receivers with serial numbers 453,400 and above.

  • Source extérieure
  • Ernst Erb
  • Source du schéma
  • Rider's Perpetual, Volume 7 = 1936 and before
  • Schémathèque (1)
  • Riders 7-3, 4

 Collections | Musées | Littérature

Collections

Le modèle Air Chief R-1661 fait partie des collections des membres suivants.

 Forum

Contributions du forum pour ce modèle: Firestone Tire &: Air Chief R-1661 Ch= R-166

Discussions: 1 | Publications: 13

Hi all. I have acquired about two dozen old receivers, mostly older Hallicrafters.

But one radio that I have a particular interest in is the Firestone Air Chief R-1661. My mother owned one and I kept it after she passed away. That particular radio is stored in my garage.

I have since bought two other R-1661s and just started testing tubes today. I looked at the schematic posted here and immediately ran into a snafu. The tube in the schematic is a 6F5. But the tube in the radio is a 6Q7 two obviously different tubes.

There is a note on the page that reads: Note: There are a few minor production changes noted on the Riders schematic (Page FIRESTONE 7-3) for receivers with serial numbers 453,400 and above. (Note again: I added the FIRESTONE to the page name.)

So I looked at that page. It looks just like the schematic posted on Radiomuseum. It does not have a 6Q7 tube in the schematic.

I am now assuming I have an earlier model of the R-1661. Or do I?

Here are some pics.



A05517-Front



A05517-Chassis





James Tippins, 14.Feb.22

Weitere Posts (13) zu diesem Thema.
