- Country
- United States of America (USA)
- Manufacturer / Brand
- Firestone Tire & Rubber Co. (Air Chief & Roamer, Airchief); Akron (OH)
- Year
- 1939 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 40808
Original condition prior to restoration
Original condition prior to restoration
Top front view prior to restoration
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 90 & 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- from Radiomuseum.org
- Model: S7428-2 - Firestone Tire & Rubber Co.
- Notes
- Built in loop antenna.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 10 = 1939 and before
- Literature/Schematics (1)
- Riders 10-7
- Other Models
-
Here you find 480 models, 313 with images and 438 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Firestone Tire & Rubber Co. (Air Chief & Roamer, Airchief); Akron (OH)
Collections
The model S7428-2 is part of the collections of the following members.
Forum contributions about this model: Firestone Tire &: S7428-2
Threads: 1 | Posts: 5
I am restoring a Firestone Firechief S-7428-2 MW radio. The schematic reflects a loop antenna or a long wire antenna. The unit I am working on is reflective a long wire antenna. My question is; the schematic does not show capacitor number 2 or resistor number 2 and installed components reflects same. Can someone be of some help here as to why? Was there a modification made not reflected on schematic? Or; is the long wire model different in the sense it does not require these two components? Thank you
Charles Keller, 25.Feb.25
