• Country
• Germany

• Manufacturer / Brand
• Funkwerk Dresden, VEB, RFT (Ostd. vorm. H. Mende & Co.)

• Year
• 1972–1980

• Category
• Commercial Transmitter & Receiver (TRX not Amateur)

• Radiomuseum.org ID
• 117588

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 27

• Semiconductors

• Main principle
• Superhet, double/triple conversion; ZF/IF 10700/470 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 2 × 7,2 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: UFT422 - Funkwerk Dresden, VEB, RFT

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 117 x 196 x 45 mm / 4.6 x 7.7 x 1.8 inch

• Notes
• BOS-Funkgerät zum Umhängen mit separatem Lautsprechermikrofon mit Sende-und Ruftaste. Ausführung für das 2-m- oder 4-m-Band mit jeweils 4 Kanälen. Modulationsart FM mit 0,4 Watt Sendeleistung. Regler für Lautstärke und Rauschsperre.

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Michael Seiffert. See "Data change" for further contributors.
