Arodyne BT
Gaveau-Radio; Paris, Asnières
- Country
- France
- Manufacturer / Brand
- Gaveau-Radio; Paris, Asnières
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 329580
La Mayenne, 13.11.1936
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Arodyne BT - Gaveau-Radio; Paris, Asnières
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 420 x 460 x 300 mm / 16.5 x 18.1 x 11.8 inch
- Notes
-
Ébénisterie bois table d'harmonie, couvercle orientable pour contrôle acoustique de tonalité.
- Price in first year of sale
- 2,290.00 FRF
- Mentioned in
- -- Original prospect or advert (La Mayenne, 13.11.1936)
