G3340/1
Geloso SA; Milano
- Country
- Italy
- Manufacturer / Brand
- Geloso SA; Milano
- Year
- 1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 99802
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Main principle
- Superheterodyne (common); ZF/IF 467/10700 kHz
- Tuned circuits
- 5 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: G3340/1 - Geloso SA; Milano
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 250 x 150 x 120 mm / 9.8 x 5.9 x 4.7 inch
- Notes
- Ricevitore per OM 180-580 mt e FM 87-108 MHz, con agganciamento automatico delle stazioni, e con tasto per la ricezione dei canali TV-suono A-B-C.
- Net weight (2.2 lb = 1 kg)
- 1.8 kg / 3 lb 15.4 oz (3.965 lb)
- Price in first year of sale
- 37,800.00 ITL
- Mentioned in
- Bollettino Tecnico Geloso (bollettino N. 90 dell' autunno 1963 pag.3)
- Author
- Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
