BC585 Table

Genalex, BGE (brand), British General Electric Co. Pty Ltd.; Sydney, NSW.

Data
Forum
Pictures
Collections

  • Year
  • 1938
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 172231

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superhet with RF-stage; ZF/IF 458 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Storage and/or dry batteries / 135 & 2 & -1.5 & -4.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: BC585 [Table] - Genalex, BGE brand, British
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • For operation from air cells for L.T., the 1D5G and 1F5G valves were used. Otherwise the 1M5G and 1L5G were used. This model became a vibrator set with a model V2 vibrator unit plugged in. When used this way the valve filaments were connected in parallel across one cell of a 6 volt storage battery and the 4 volt vibrator unit was connected across the other two cells. This radio had three position switched variable selectivity. The price below includes batteries but not the vibrator unit. See model BC580 for vibrator unit details.
  • Price in first year of sale
  • 30.00 Aus£
  • Circuit diagram reference
  • Australian Official Radio Service Manual Vol. I I
  • Author
  • Model page created by Stuart Irwin. See "Data change" for further contributors.
