Colorama E-105

General Electric Co. (GE); Bridgeport CT, Syracuse NY

Données
Forum
Images
Collections

  • Année
  • 1936
  • Catégorie
  • Radio - ou tuner d'après la guerre 1939-45
  • Radiomuseum.org ID
  • 42027
    • Brand: Musaphonic

Cliquez sur la vignette du schéma pour le demander en tant que document gratuit.

 Spécifications techniques

  • No. de tubes
  • 10
  • Principe général
  • Super hétérodyne avec étage HF; FI/IF 465 kHz; 2 Etage(s) BF
  • Circuits accordés
  • 9 Circuits MA (AM)
  • Gammes d'ondes
  • GO, OC et Police (Maritime)
  • Tension / type courant
  • Alimentation Courant Alternatif (CA) / 25 or 60 cycles: 105 - 120 or 115; 125; 220; 240 Volt
  • Haut-parleur
  • HP dynamique à électro-aimant (électrodynamique) / Ø 12 inch = 30.5 cm
  • Puissance de sortie
  • 6.5 W (14 W max.)
  • Matière
  • Boitier en bois
  • De Radiomuseum.org
  • Modèle: Colorama E-105 - General Electric Co. GE;
  • Forme
  • Console de forme générique
  • Dimensions (LHP)
  • 25 x 40 x 11.8 inch / 635 x 1016 x 300 mm
  • Remarques
  • The General Electric models E-101, E-105 and E-106 share the same schematic (Rider's GE 7-29 through 7-32) and feature the Colorama tuning indicator (see post 5 etc.). The triode 6C5 commands depending on the AGC line the saturation of the "magnetic amplifier", a saturable core reactor. The reactor is in series with a row of 4 red stained pilot lamps and 3 green stained light bulbs behind the scale which turn the light to green when a carrior (station) is tuned in. Weak stations will produce a small color change and strong stations larger changes - a smooth process. This was then a novelty for GE sets - the Magic Eye was just on the market but GE wanted first to have it's own gadget which was a problem to service men and the cost was over twice that of teh tuning eye.

    The 6J7 is for the AFC - not applied for the models E-91 and E-95. All these models can have a 25 cycle (C) or 60 cycle mains transformer which came in two versions, one fix for 105-120 volts (A), the other for 105 to 250 volts with 4 tappings (V). The band B (Broadcast) covers 540 - 1680 kc, the band C (Fishery, Police etc.) 1680 - 6000 kc and band D (SW) 6 - 18 mc.
  • Poids net
  • 72 lb (72 lb 0 oz) / 32.688 kg
  • Prix de mise sur le marché
  • 100.00 $
  • Source extérieure
  • Ernst Erb
  • Source du schéma
  • Rider's Perpetual, Volume 7 = 1936 and before
