Inconnu - Unknown 54 Cadran Condensateurs "Star"
Unknown - CUSTOM BUILT: France (INCONNU)
- Country
- France
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: France (INCONNU)
- Year
- 1934 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 129256
Rückseite - hat das Gerät eine Rückwand?
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 130 kHz; 2 AF stage(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Inconnu - Unknown 54 Cadran Condensateurs "Star" - Unknown - CUSTOM BUILT: France
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 360 x 477 x 257 mm / 14.2 x 18.8 x 10.1 inch
- Notes
-
Condensateur variable et cadran marque Star.
Voir aussi modèle similaire GMR Echo 375 et autres.
- Author
- Model page created by Johann Hieninger. See "Data change" for further contributors.
- Other Models
-
Here you find 268 models, 251 with images and 16 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Unknown - CUSTOM BUILT: France (INCONNU)
Collections
The model Inconnu - Unknown 54 is part of the collections of the following members.
