Psyché 35

Gody, Abel; Amboise (Indre-et-Loire)

Data
Forum
Pictures
Collections

  • Year
  • 1934 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 291771

 Technical Specifications

  • Number of Tubes
  • 8
  • Valves / Tubes
  • Main principle
  • Superhet with RF-stage
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Psyché 35 - Gody, Abel; Amboise Indre-et-
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 420 x 390 x 260 mm / 16.5 x 15.4 x 10.2 inch
  • Notes

  • Cadran lumixeux interchangéable à lecture directe, à miroir orientable.

    Voir aussi modèle similaire Gody-Psyché de l'année 1933.

    Le modèle est mentionnée dans Guide Biraud Vol III. Le nom Psyché 35 n'est pas certain.

  • Net weight (2.2 lb = 1 kg)
  • 15 kg / 33 lb 0.6 oz (33.04 lb)
  • Author
  • Model page created by Manfred Rathgeb. See "Data change" for further contributors.
