Unigor 3p

• Country
• Austria

• Manufacturer / Brand
• Goerz Electro Ges.m.b.H., Wien

• Year
• 1967 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 181133

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Unigor 3p - Goerz Electro Ges.m.b.H., Wien

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 110 x 90 x 212 mm / 4.3 x 3.5 x 8.3 inch

• Notes
• Vielfachmessinstrument.
  Messbereich V AC/DC; 100 mV bis 1000 V (5000 V).
  Messbereich A AC/DC: 0,1 A bis 5 A.
  Im Ohmbereich sind 5 Messbereiche möglich.

• Net weight (2.2 lb = 1 kg)
• 1.2 kg / 2 lb 10.3 oz (2.643 lb)

• Price in first year of sale
• 494.00 DM

• Source of data
• -- Collector info (Sammler)

• Mentioned in
• Conrad Katalog B28 von 1971

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
