- Country
- France
- Manufacturer / Brand
- Grammont (Radiofotos, Fotos); Paris, Malakoff
- Year
- 1962/1963
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 321223
-
- alternative name: Radiofotos || Société des lampes Fotos
- Number of Tubes
- 16
- Valves / Tubes
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Goya - Grammont Radiofotos, Fotos;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 610 x 450 x 320 mm / 24 x 17.7 x 12.6 inch
- Notes
-
Téléviseur 10 canaux, reçoit standard français 819 lignes, prévu pour la reception sur bande I et IV sur 625 lignes (avec tuner en option).
Écran 48 cm, déviation 110°. HP elliptique de 10 x 14 cm.
Anti-parasites par adaptateur. CAG. Effacement lignes15 tubes (+ CRT?), 2 redresseurs secs, 2 "divers".
- Net weight (2.2 lb = 1 kg)
- 33 kg / 72 lb 11 oz (72.687 lb)
- Price in first year of sale
- 1,357.36 FRF
- Mentioned in
- La TSF pour TOUS - TSF et TV (Revue mensuelle) (Sept. 1962, Téléviseurs Saison 62/63)
