• Country
• France

• Manufacturer / Brand
• Grammont (Radiofotos, Fotos); Paris, Malakoff

• Year
• 1933 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 121553

• • alternative name: Radiofotos || Société des lampes Fotos

• Number of Tubes
• 7

• Valves / Tubes
• 56 58 58 58 55 A247 80

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 22 cm = 8.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Super 2030 - Grammont Radiofotos, Fotos;

• Shape
• Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.

• Dimensions (WHD)
• 402 x 540 x 320 mm / 15.8 x 21.3 x 12.6 inch

• Notes
• Wellenbereiche: 2 x LW, 2 x MW.

• Net weight (2.2 lb = 1 kg)
• 17.9 kg / 39 lb 6.8 oz (39.427 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.

• Other Models

• Here you find 163 models, 120 with images and 65 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
