• Country
• France

• Manufacturer / Brand
• Grandin, Cristal-Grandin (SFRT); Paris, Montreuil

• Year
• 1955 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216129

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH81 6BA6 6AV6 EL84 EM80 or EM85 6V4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19 cm = 7.5 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Symphonie 666BK Plan 019-178 - Grandin, Cristal-Grandin SFRT;

• Shape
• Tablemodel with Push Buttons.

• Notes

• 4 gammes d'ondes GO, PO, OC, BE. Cadre à air bindé orientable.

  Coffret bakélite.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Franz-Josef Haffner. See "Data change" for further contributors.
