- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1979 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 119552
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 220-240 / 4 × 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: CR110 - Grundig Radio-Vertrieb, RVF,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 180 x 65 x 265 mm / 7.1 x 2.6 x 10.4 inch
- Notes
- Stereo-Aufnahme und-Wiedergabe. Übertragungsbereich 100Hz-10kHz. Steuerung der Start/Stop Funktion über Grundig Satellit 400/500/650 möglich. Tastenbezeichnungen in Blindenschrift.
Laut Original-Verpackung "Personal Computer Compatible" (Datenspeicherung und Rückspielung auf zeitgenössische Computer mit Kassetteninterface)
Gehäusevarianten: schwarz oder weinrot
- Net weight (2.2 lb = 1 kg)
- 1 kg / 2 lb 3.2 oz (2.203 lb)
- Source of data
- -- Collector info (Sammler)
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Ralf Krebs. See "Data change" for further contributors.
