TK47

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1962–1964

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 24611

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• EF86 EF86 ECC81 ECC81 EM84 ECC83 ELL80 EL95

• Number of Transistors

• Semiconductors
• M3 M3 B250C100

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder; Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: TK47 - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 510 x 210 x 400 mm / 20.1 x 8.3 x 15.7 inch

• Notes
• Zweispur Stereo; Bandgeschwindigkeiten: 4,75/9,5/19 cm/s. Spulen-Ø 18 cm. Stereo-NF-Verstärker mit 2 Endstufen je 3 W. Start/Stop-Fernbedienung nachrüstbar (DM 9,-).

• Net weight (2.2 lb = 1 kg)
• 14.8 kg / 32 lb 9.6 oz (32.599 lb)

• Price in first year of sale
• 898.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1962/1963

• Literature/Schematics (1)
• -- Original-techn. papers.
