Wechselsprechanlage DWA 293
Hartig & Helling, H&H; Essen und Bochum
- Country
- Germany
- Manufacturer / Brand
- Hartig & Helling, H&H; Essen und Bochum
- Year
- 1997 ??
- Category
- Telephony - wire and wireless
- Radiomuseum.org ID
- 344708
- Number of Transistors
- 6
- Main principle
- Special principle (see notes)
- Wave bands
- Wave Bands given in the notes.
- Details
- Wired Wireless Receiver (RF!)
- Power type and voltage
- Alternating Current supply (AC) / 220 - 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Wechselsprechanlage DWA 293 - Hartig & Helling, H&H; Essen
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 175 x 48 x 130 mm / 6.9 x 1.9 x 5.1 inch
- Notes
-
Netzgebundene Wechselsprechanlage mit Ruf- und Überwachungsfunktion (Auto-Taste). Das Sprechsignal wird über das Niederspannungs-Hausnetz übertragen. 2 umschaltbare Kanäle: I und II. Die Netzsteckdosen müssen dabei an die gleiche Phase angeschlossen sein, ansonsten ist ein Phasenkoppler erforderlich. Wandmontage möglich.
Leistungsaufnahme: 2 Watt.
- Net weight (2.2 lb = 1 kg)
- 0.550 kg / 1 lb 3.4 oz (1.211 lb)
- Author
- Model page created by Michael Mischke. See "Data change" for further contributors.
