• Country
• Austria

• Manufacturer / Brand
• HEA; Wien

• Year
• 1969/1970

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 62790

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 30 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Steuergerät 4000 - HEA; Wien

• Shape
• Book-shelf unit.

• Notes
• ICs: 1

• Price in first year of sale
• 3,500.00 ATS

• Source of data
• -- Collector info (Sammler) / Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Gerhard Heigl. See "Data change" for further contributors.
