Studio 4060 FM Recorder
HEA; Wien
- Country
- Austria
- Manufacturer / Brand
- HEA; Wien
- Year
- 1975
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 226512
willhaben.at, willhaben-Code: 415744643
willhaben.at, willhaben-Code: 415744643
willhaben.at, willhaben-Code: 415744643
Prospektbild
willhaben.at, willhaben-Code: 415744643
willhaben.at, willhaben-Code: 415744643
willhaben.at, willhaben-Code: 415744643
willhaben.at, willhaben-Code: 415744643
willhaben.at, willhaben-Code: 415744643
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- FM Broadcast Band Only
- Details
- Other Combination - see Notes
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 40 W (undistorted)
- Material
- Various materials
- from Radiomuseum.org
- Model: Studio 4060 FM [Recorder] - HEA; Wien
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 675 x 150 x 385 mm / 26.6 x 5.9 x 15.2 inch
- Notes
-
Mit Plattenspieler: Lenco L65
Cassetten-Recorder: Hea 1001
Ausgangsleistung 2 × 20 Watt Sinus.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
