• Country
• Austria

• Manufacturer / Brand
• HEA; Wien

• Year
• 1965 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 62795

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors
• AF185 AF125 AF125 AF127 AF127 AC126 AC126 AC128 AC128 AD149 AD149

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Vienna E - HEA; Wien

• Shape
• Chassis only or for «building in»

• Notes

• -

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Gerhard Heigl. See "Data change" for further contributors.

• Other Models

• Here you find 195 models, 138 with images and 157 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
