Olympic W59T435A /00 /03 Ch= F2N
Horny (Hornyphon); Wien
- Country
- Austria
- Manufacturer / Brand
- Horny (Hornyphon); Wien
- Year
- 1966
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 86809
-
- Brand: Hornyphon
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Valves / Tubes
- PC900 PCF801 PCF201 PCF200 PCL84 PL84 PCL86 PCH200 PCL85 PCF802 PL500 PY81 DY87 A59-11W
- Number of Transistors
- 3
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Olympic W59T435A /00 /03 Ch= F2N - Horny Hornyphon; Wien
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 710 x 510 x 370 mm / 28 x 20.1 x 14.6 inch
- Notes
-
Fernsehband VHF (I+III), UHF (IV/V). 59-cm-Rechteckbildröhre.
2 Ausführungen:
/00= nuß-hochglänzend;
/03= nuß-seidenglanz.Paralleltype zum Philips 23TA534A.
- Net weight (2.2 lb = 1 kg)
- 25 kg / 55 lb 1.1 oz (55.066 lb)
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
