• Country
• Austria

• Manufacturer / Brand
• Horny (Hornyphon); Wien

• Year
• 1969

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 62917

• • Brand: Hornyphon

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors
• BF195 BF195 BF167 BF167 BF167 BF167 BC149 BC149 BC158 AC117 AC175 AD155

• Main principle
• Superheterodyne (common); ZF/IF 462 kHz; 7 AF stage(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 3.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Prinzess 70 W4349 [/00 /02] - Horny Hornyphon; Wien

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 480 x 165 x 195 mm / 18.9 x 6.5 x 7.7 inch

• Notes
• 2 Ausführungen:
  /00 = dunkel, hochglänzend,
  /02 = hell, matt.
  Das Gerät Horny Prinzess 70 wurde bei Kapsch gebaut. Das Chassis ist ident mit dem Kapsch Troubadour TR.

• Net weight (2.2 lb = 1 kg)
• 4.3 kg / 9 lb 7.5 oz (9.471 lb)

• Price in first year of sale
• 1,895.00 ATS

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Gerhard Heigl. See "Data change" for further contributors.
