Cosmos W bis Gerät Nr 142.600
Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
- Country
- Austria
- Manufacturer / Brand
- Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
- Year
- 1953 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 275708
-
- Brand: Elektrot.Fabrik Ludwig Neumann
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 451 or 459 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Cosmos W bis Gerät Nr 142.600 - Ingelen, Elektrotechnische
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Siehe auch Ingelen Cosmos W ab Nr. 142.601
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Rudolf Müller. See "Data change" for further contributors.
