Fidelio 57 3D Luxus Super W

• Country
• Austria

• Manufacturer / Brand
• Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien

• Year
• 1957/1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 62835

• • Brand: Elektrot.Fabrik Ludwig Neumann

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EBF89 EF89 EM81 EABC80 EL84

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110, 130, 150, 220, 240 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Fidelio 57 3D Luxus Super W - Ingelen, Elektrotechnische

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 610 x 385 x 245 mm / 24 x 15.2 x 9.6 inch

• Notes
• TrGl.

• Net weight (2.2 lb = 1 kg)
• 13 kg / 28 lb 10.1 oz (28.634 lb)

• Price in first year of sale
• 3,290.00 öS

• Source of data
• -- Collector info (Sammler) / Radiokatalog Band 2, Ernst Erb

• Mentioned in
• RADIOBOTE, Österr. (Heft 74/2018, S.8 ff, Beschreibung und Restaurierung)

• Author
• Model page created by Gerhard Heigl. See "Data change" for further contributors.
