• Country
• Austria

• Manufacturer / Brand
• Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien

• Year
• 1964

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 84859

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 13

• Valves / Tubes
• PCC189 PCF86 PCL84 ECH84 PCL86 PCF80 PCF80 PCF802 PL500 PY88 DY87 PCL85 A59-11W

• Number of Transistors
• 5

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Bellevue Automatic - Kapsch & Söhne KS, Telephon-

• Shape
• Tablemodel with Push Buttons.

• Notes
• Fernsehbänder: VHF Band I+III, UHF Band IV/V. 59-cm-Bildröhre. Auch als nur "UHF vorbereitet" um 5490.- ATS.

• Price in first year of sale
• 5,980.00 ATS

• Source of data
• -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
