• Country
• Austria

• Manufacturer / Brand
• Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien

• Year
• 1933/1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 9366

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• TRF without regeneration

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Dynamik-Volksempfänger Brillant Katalog Nr. 11841 - Kapsch & Söhne KS, Telephon-

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Net weight (2.2 lb = 1 kg)
• 7.8 kg / 17 lb 2.9 oz (17.181 lb)

• Price in first year of sale
• 190.00 öS

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• -- Original prospect or advert (Radio Wien, 17.03.1933, 26.05.1933)

• Picture reference
• Das Modell ist im «Radiokatalog» (Erb) abgebildet.

• Other Models

• Here you find 614 models, 507 with images and 378 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
