• Country
• Austria

• Manufacturer / Brand
• Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien

• Year
• 2017

• Category
• Digital terrestrial, Internet and SAT receiver (also analogue)

• Radiomuseum.org ID
• 297148

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• DAB and FM, perhaps with Streaming [DABFM]

• Details
• Other Combination - see Notes; Radio with other functions

• Power type and voltage
• Line / Storage batteries (perhaps also batteries) / 230 / 18 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm

• Power out
• 10 W (max.)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Capri 125 plus - Kapsch & Söhne KS, Telephon-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 222.7 x 155.4 x 73 mm / 8.8 x 6.1 x 2.9 inch

• Notes

• Retro-Design-Kofferradio zum 125-jährigen Firmenjubiläum 2017, mit Leder bezogenes Gehäuse, Farbdisplay.

  Wiedergabemodi Bluetooth/Aux-IN/UKW/DAB+/Internet Radio/Spotify/ Music player.

  Limitierte und nummerierte Auflage (2000) in Geschenkbox.
  Siehe auch das Original von 1958/59 Kapsch Capri als reines MW-Radio.

  Made in China by Guangzhou Rayer Acoustic Technology Co., Ltd.

• Net weight (2.2 lb = 1 kg)
• 1 kg / 2 lb 3.2 oz (2.203 lb)

• Price in first year of sale
• 399.00 €

• Source of data
• - - Manufacturers Literature

• Mentioned in
• -- Original prospect or advert ("bild der wissenschaft" Jan. 2018)

• Literature/Schematics (1)
• RADIOBOTE, Österr. (Heft 75/2018, S.3 ff, Gerätebeschreibung)

• Literature/Schematics (2)
• - - Manufacturers Literature (User Manual)

Benutzerhandbuch zum Kapsch Capri 125 Plus

1273 KB

• Documents regarding this model

• Author
• Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
