• Country
• Austria

• Manufacturer / Brand
• Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien

• Year
• 1955/1956

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 88941

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EF85 EABC80 EM34 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 461 kHz

• Tuned circuits
• 7 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Concerto - Kapsch & Söhne KS, Telephon-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 540 x 355 x 230 mm / 21.3 x 14 x 9.1 inch

• Notes
• 3-D-Raumklang.

• Net weight (2.2 lb = 1 kg)
• 11.2 kg / 24 lb 10.7 oz (24.67 lb)

• Price in first year of sale
• 2,360.00 ATS

• Source of data
• -- Original prospect or advert

• Mentioned in
• Museums Bote, Österr. (Heft 121/2004, S.11, Kurzbeschreibung)

• Author
• Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
